QSM / Tru-Flo
QSM DISC CHECK VALVE 0.75" TC 316L EPDM SEAL
CSE-316L-TC-E-0.75
- MPN:
- CSE-316L-E-.75"
Net Price: $184.15 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | QSM / Tru-Flo |
|---|---|
| Product Type | Valves |
| Product Subtype | Check Valves |
| Series | CSE Series |
| Material | 316L Stainless Steel |
| Elastomer | EPDM |
| Size 1 | 0.75" |
| Connection Type 1 | Tri-Clamp |
| Weight | 1.00000 |
- Manufacturer:
- QSM Inc
- MPN:
- CSE-316L-E-.75"
Dimensional Data
QSM CSE-316L Tri-Clamp Disc Check Valve
| Nominal Size | A | B | |||
|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) |
| ½ | 12.70 | 1.54 | 39.12 | 1.10 | 27.94 |
| ¾ | 19.05 | 1.54 | 39.12 | 1.10 | 27.94 |
| 1 | 25.40 | 2.32 | 58.93 | 1.65 | 41.91 |
| 1½ | 38.10 | 2.32 | 58.93 | 1.65 | 41.91 |
| 2 | 50.80 | 2.32 | 58.93 | 1.65 | 41.91 |
| 2½ | 63.50 | 2.32 | 58.93 | 1.65 | 41.91 |
| 3 | 76.20 | 2.32 | 58.93 | 1.65 | 41.91 |
| 4 | 101.60 | 2.60 | 66.04 | 2.32 | 58.93 |
QSM CSE Data Sheet
