WILDEN SURGE DAMPENER 2" FPT POLY WET SIDE AL CHAMBER POLY REGULATOR PTFE WITH NEOPRENE BACKUP DIAPHRAGM PTFE ENCAPSULATED VITON SEALS

SD-2-PAPTFTV

MPN:
71-7317

Net Price: $2,145.70 / EA

Have an account? Login now.

This item is non-returnable.

Availability:
Brand Wilden
Product Type Pumps
Product Subtype Surge Dampeners
Series SD Series
Material Polypropylene
Connection Type 1 FNPT
Diaphragm Material Teflon / Neoprene
Weight 27.90000
Manufacturer:
PSG California LLC
MPN:
71-7317

SD2 Dimensional Diagram

Surge Dampener | SD-2PAPTFTV-Size-Material-Finish
  A B C D E
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
Metal 12.0 305 9.8 249 13.8 351 17.9 455 9.6 244
Plastic  13.5 343 10.5 267 13.8 351 19.4 493 10.8 274
