AIR BLOW CHECK VALVE 4.5" TC 1" HOSE BARB EPDM LOW VOLUME ALFA LAVAL

62-174R-B-4.5

MPN:
9634054669

Net Price: $720.11 / EA

Have an account? Login now.

Availability:
  • Total: 1
Product Availability
Price
STEM ASSEMBLY EPDM FOR 62-174 AIR BLOW CHECK VALVE ALFA LAVAL

$61.37 / EA

  • Total: 1
Brand Alfa Laval
Product Type Valves
Product Subtype Air Blow Check Valves
Series 62-174 Series
Material 316L Stainless Steel
Size 1 4.5"
Connection Type 1 Tri-Clamp
Size 2 1"
Connection Type 2 Hose Barb
Specification / Standard 3-A
Weight 0.00000
Manufacturer:
Alfa Laval Inc
MPN:
9634054669

62-174 and 326 Dimensional Diagram

62-174 Air Blow Check Valve
Nominal Size A B
"A" Adapter "B" Adapter "C" or "C1" Adapter
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
1½ 38.10 1.94 49.28 2.50 63.50 3.00 76.20 2.00 50.80
2 50.80 2.50 63.50 2.50 63.50 3.00 76.20 2.00 50.80
2½ 63.50 2.06 52.32 2.50 63.50 3.00 76.20 2.00 50.80
3 76.20 3.56 90.42 2.50 63.50 3.00 76.20 2.00 50.80
4 101.60  4.69  119.13  2.50 63.50 3.00 76.20 2.00 50.80
4½ 114.30  5.13  130.30  2.50 63.50 3.00 76.20 2.00 50.80
