Alfa Laval
Alfa Laval 700 Series Y-Body Valve 2.5" Tri-Clamp 316L Buna 4.5" Actuator Normally Closed
761TR-90M-20L-2.5-1422-50
- MPN:
- 9634095319
Net Price: $4,746.47 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | Alfa Laval |
|---|---|
| Product Type | Valves |
| Product Subtype | Seat Valves |
| Series | 700 Series |
| Model | 761TR |
| Material | 316L Stainless Steel |
| Elastomer | Buna |
| Size 1 | 2.5" |
| Connection Type 1 | Tri-Clamp |
| Weight | 30.67000 |
- Manufacturer:
- Alfa Laval Inc
- MPN:
- 9634095319
Dimensional Data
761-90 Shutoff Y-Body Tri-Clamp Single Seat Valve
| Nominal Size | A | C | |||
|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 1½ | 38.10 | 20.63 | 524.00 | 22.31 | 566.67 |
| 2 | 50.80 | 22.38 | 568.45 | 24.63 | 625.60 |
| 2½ | 63.50 | 22.94 | 582.68 | 25.44 | 646.18 |
| 3 | 76.20 | 28.94 | 735.08 | 29.69 | 754.13 |
| 4 | 101.60 | 32.13 | 816.10 | 32.88 | 835.15 |
Resources
0Data Sheets
1Manuals
-
Alfa Laval 700 Series Manual
-
Alfa Laval 741 761 762 771 Air Actuated Valves Manual
-
Tri-Clover 700 Series Manual (Legacy)
