ALL-FLO A300 DIAPHRAGM PUMP 3" NPT BOLTED METAL ALUMINUM WET SIDE ALUMINUM AIR SIDE PTFE DIAPHRAGM PTFE VALVE BALL 316 STAINLESS STEEL SEATS PTFE O-RINGS AODD

A300-NAA-TT3T-B30

USUALLY SHIPS IN 1-3 DAYS

Net Price: $5,737.00 / EA

Have an account? Login now.

Availability:
  • Total: 2
Product Availability
Price
ALL-FLO REPAIR KIT AIR 3" BOLTED ALUMINUM

$476.10 / EA

ALL-FLO REPAIR KIT WET 3" BOLTED METAL PTFE

$2,195.80 / EA

  • Total: 2
Brand All-Flo
Product Type Pumps
Product Subtype Diaphragm Pumps
Series A Series
Model A300
Material Aluminum
Size 1 3"
Connection Type 1 NPT
Diaphragm Material PTFE (Teflon)
Weight 150.00000

A300 Dimensional Diagram (Bolted, Dimensions A, B, C, D, and E)A300 Dimensional Diagram (Bolted, Dimensions F, G, and H)A300 Dimensional Diagram (Bolted, Dimensions I, J, K, L, M, N, O, and P)

Air-Operated Double-Diaphragm Pump (Bolted) | A300
Size A B C D E F G H I J K L M N O P
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
3.00 76.20 30.20 767.08 16.50 419.10 2.50 63.50 12.40 314.96 24.80 629.92 3.30 83.82 32.60 828.04 16.80 426.72 0.60 15.24 11.20 284.48 10.20 259.08 5.80 147.32 3.90 99.06 7.70 195.58 12.10 307.34 14.30 363.22
