PHARMA FLOW PRESSURE GAUGE 1.5" TC BACK MOUNT 0 TO 100 PSI NO FILL POLYCARBONATE LENS 3.5" DIAL
3P-D-15U-NF-BK-CG-MTR-CC-CSI
$542.00 / EA
Spare Parts
Suggested products
Attributes
Brand | Chicago Stainless |
---|
Product Type | Instrumentation |
---|
Product Subtype | Pressure |
---|
Series | Pharma-Flow Series |
---|
Size | 1.5" |
---|
Connection Type | Tri-Clamp |
---|
Material | 316L Stainless Steel |
---|
Specification / Standard | 3-A Compliant |
---|
Orientation / Mount | Back |
---|
Weight | 0.00000 |
---|
- Manufacturer:
- Chicago Stainless Equipment
- Manufacturer part number:
- 3P-D-15U-NF-BK-CG-MTR-CC-CSI
Dimensional Data
Pharma-Flow Pressure Gauge Tri-Clamp Back Mount
Gauge Size | A | B | C | ||||
---|---|---|---|---|---|---|---|
(in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
2½ | 63.50 | 1.88 | 48.00 | 3.44 | 87.00 | 3.69 | 94.00 |
3½ | 88.90 | 1.88 | 48.00 | 3.44 | 87.00 | 3.69 | 94.00 |
5 | 127.00 | 2.31 | 59.00 | 3.75 | 95.00 | 5.06 | 129.00 |
