ECCENTRIC REDUCER 3X2 BW 316L 32RA ID 32RA OD
L32-3X2-316L-7
$19.92 / EA
- Availability:
-
Springfield, MO 146 EA Durham, NC 0 EA Modesto, CA 38 EA Grand Prairie, TX 276 EA
Spare Parts
Dimensional Data
Eccentric Butt Weld Reducers, Short | L32-Size-Material-Finish
| Nominal Size | A | ||
|---|---|---|---|
| (in) | (mm) | (in) | (mm) |
| 1 x ½ | 25.40 x 12.70 | 2.00 | 50.80 |
| 1 x ¾ | 25.40 x 19.05 | 1.00 | 25.40 |
| 1½ x ½ | 38.10 x 12.70 | 4.00 | 101.60 |
| 1½ x ¾ | 38.10 x 19.05 | 3.00 | 76.20 |
| 1½ x 1 | 38.10 x 25.40 | 2.00 | 50.80 |
| 2 x 1 | 50.80 x 25.40 | 4.00 | 101.60 |
| 2 x 1½ | 50.80 x 38.10 | 2.00 | 50.80 |
| 2½ x 1½ | 63.50 x 25.40 | 4.75 | 120.65 |
| 2½ x 2 | 63.50 x 50.80 | 2.00 | 50.80 |
| 3 x 1½ | 76.20 x 38.10 | 6.00 | 152.40 |
| 3 x 2 | 76.20 x 50.80 | 4.00 | 101.60 |
| 3 x 2½ | 76.20 x 63.50 | 2.00 | 50.80 |
| 4 x 1½ | 101.60 x 38.10 | 10.00 | 254.00 |
| 4 x 2 | 101.60 x 50.80 | 8.00 | 203.20 |
| 4 x 2½ | 101.60 x 63.50 | 6.00 | 152.40 |
| 4 x 3 | 101.60 x 76.20 | 4.00 | 101.60 |
| 6 x 3 | 152.40 x 76.20 | 5.50 | 139.70 |
| 6 x 4 | 152.40 x 101.60 | 5.50 | 139.70 |
Resources
Attributes
- Alloy/Material:
- 316 / 316L
- Connection Type:
- Weld
- Finish:
- 32Ra ID / 32Ra OD
- Reducing Size:
- 2"
- Size:
- 3"
- Specification/Standard:
- Sanitary Fittings
- Weight:
- 0.6
