Advanced Couplings (ACL)

CLAMP SINGLE BOLT DOUBLE PIN 2.5" 316 SH TYPE CL.SH.0250 C025.6.SH1 ADVANCED COUPLINGS

SHWN0007706

USUALLY SHIPS IN 1-2 DAYS

Net Price: $31.75 / EA

Availability:

Spare Parts

Attributes

Brand	Advanced Couplings (ACL)
Product Type	Tube Fittings
Product Subtype	Clamps
Material	316 Stainless Steel
Size 1	2.5"
Connection Type 1	Tri-Clamp
Fitting Design	SH Double Pin With Wing Nut
Weight	0.94000

Dimensional Data

ACL SH Single Bolt Clamp Dimensional Diagram

SH Single Bolt Clamp Dimensional Diagram

Nut Type	Size		A		B		C		Width
	(in)	(mm)	(in)	(mm)	(in)	(mm)	(in)	(mm)	(in)	(mm)
Wing	0.50	12.70	0.98	24.89	2.55	64.77	2.95	74.93	0.67	17.02
Hex	0.50	12.70	0.98	24.89	2.48	62.99	2.95	74.93	0.67	17.02
Wing	0.75	19.05	0.98	24.89	2.55	64.77	2.95	74.93	0.67	17.02
Hex	0.75	19.05	0.98	24.89	2.48	62.99	2.95	74.93	0.67	17.02
Wing	0.68	17.20	1.34	34.04	2.64	67.06	3.35	85.09	0.67	17.02
Hex	0.68	17.20	1.34	34.04	2.28	57.91	2.95	74.93	0.67	17.02
Wing	0.84	21.34	1.34	34.04	2.64	67.06	3.35	85.09	0.67	17.02
Hex	0.84	21.34	1.34	34.04	2.28	57.91	2.95	74.93	0.67	17.02
Wing	1.05	26.67	1.34	34.04	2.64	67.06	3.35	85.09	0.67	17.02
Hex	1.05	26.67	1.34	34.04	2.28	57.91	2.95	74.93	0.67	17.02
Wing	1.00	25.40	1.99	50.55	3.03	76.96	4.02	102.11	0.67	17.02
Hex	1.00	25.40	1.99	50.55	2.68	68.07	4.02	102.11	0.67	17.02
Wing	1.50	38.10	1.99	50.55	3.03	76.96	4.02	102.11	0.67	17.02
Hex	1.50	38.10	1.99	50.55	2.68	68.07	4.02	102.11	0.67	17.02
Wing	2.00	50.80	2.52	64.01	3.66	92.96	4.84	122.94	0.67	17.02
Hex	2.00	50.80	2.52	64.01	2.87	72.90	4.84	122.94	0.67	17.02
Wing	2.50	63.50	3.05	77.47	3.94	100.08	5.51	139.95	0.67	17.02
Hex	2.50	63.50	3.05	77.47	3.07	77.98	5.51	139.95	0.67	17.02
Wing	3.00	76.20	3.58	90.93	4.13	104.90	5.91	150.11	0.67	17.02
Hex	3.00	76.20	3.58	90.93	3.35	85.09	5.91	150.11	0.67	17.02
Wing	3.50	88.90	4.17	105.92	4.33	109.98	6.50	165.10	0.67	17.02
Hex	3.50	88.90	4.17	105.92	3.62	91.95	6.50	165.10	0.67	17.02
Wing	4.00	101.60	4.69	119.13	4.69	119.13	7.28	184.91	0.67	17.02
Hex	4.00	101.60	4.69	119.13	3.82	97.03	7.28	184.91	0.67	17.02
Wing	4.50	114.30	5.11	129.79	4.69	119.13	7.52	191.01	0.67	17.02
Hex	4.50	114.30	5.11	129.79	4.02	102.12	7.52	191.01	0.67	17.02
Wing	5.00	127.00	5.67	144.02	5.16	131.06	8.46	214.88	0.75	19.05
Hex	5.00	127.00	5.67	144.02	4.37	112.00	8.46	214.88	0.75	19.05
Wing	5.50	139.70	6.10	154.94	6.10	154.94	9.92	251.97	0.94	23.88
Hex	5.50	139.70	6.10	154.94	4.96	125.98	9.92	251.97	0.94	23.88
Wing	6.00	152.40	6.57	166.88	6.14	155.96	10.32	262.13	0.94	23.88
Hex	6.00	152.40	6.57	166.88	5.12	130.05	10.32	262.13	0.94	23.88
Wing	6.63	168.40	7.20	182.88	6.46	164.08	11.02	279.91	0.94	23.88
Hex	6.63	168.40	7.20	182.88	5.35	135.89	11.02	279.91	0.94	23.88
Wing	8.00	203.20	8.54	216.92	7.24	183.90	12.80	325.12	0.94	23.88
Hex	8.00	203.20	8.54	216.92	6.06	153.92	12.80	325.12	0.94	23.88
Wing	8.63	219.20	9.17	232.92	6.46	164.08	13.11	332.99	0.94	23.88
Hex	8.63	219.20	9.17	232.92	7.28	184.91	13.11	332.99	0.94	23.88
Wing	10.00	254.00	10.55	267.97	7.13	181.10	10.42	264.67	0.94	23.88
Hex	10.00	254.00	10.55	267.97	8.07	204.98	10.42	264.67	0.94	23.88
Wing	10.63	270.00	11.26	286.00	8.39	213.11	15.94	404.88	0.94	23.88
Hex	10.63	270.00	11.26	286.00	7.48	189.99	15.94	404.88	0.94	23.88
Wing	12.00	304.80	12.56	319.02	9.53	242.06	18.03	457.96	0.94	23.88
Hex	12.00	304.80	12.56	319.02	8.50	215.90	16.93	430.02	0.94	23.88
Wing	12.63	320.80	13.33	338.58	9.57	243.08	18.23	463.04	0.94	23.88
Hex	12.63	320.80	13.33	338.58	8.39	213.11	16.73	424.94	0.94	23.88
