CLAMP THREE SEGMENT 1" 1.5" 304 CL.3S.0100 ADVANCED COUPLINGS

S3WN0005004

USUALLY SHIPS IN 1-2 DAYS

Net Price: $24.22 / EA

Have an account? Login now.

Availability:
Brand Advanced Couplings (ACL)
Product Type Tube Fittings
Product Subtype Clamps
Material 304 Stainless Steel
Size 1 1"-1.5"
Connection Type 1 Tri-Clamp
Fitting Design 3 Segment with Wing Nut
Weight 0.37000

ACL Dairy and Food 3-Segment Clamp Dimensional Diagram

Dairy & Food 3-Segment Clamp Dimensional Diagram
 Size A B C Width
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
1.00 25.40 1.99 50.55 3.01 76.45 3.22 81.79 0.75 19.05
1.50 38.10 1.99 50.55 3.01 76.45 3.22 81.79 0.75 19.05
2.00 50.80 2.52 64.01 3.23 82.04 3.68 93.47 0.77 19.56
2.50 63.50 3.05 77.47 3.43 87.12 4.29 108.97 0.77 19.56
3.00 76.20 3.58 90.93 3.78 96.01 4.98 126.49 0.77 19.56
4.00 101.60 4.69 119.13 4.88 123.95 5.91 150.11 0.77 19.56
