ITT / Envizion
ENV-2-F-419-SF2-0-0-TMZ-ZB2 DIAPHRAGM VALVE 2" TC FORGED SF2 25RA ID TMZ MODIFIED PTFE ZB2 ENVIZION ZERO TORQUE ADVANTAGE ACTUATOR ITT
PF-V-702229
- MPN:
- ENV-2-F-419-SF2-0-0-TMZ-ZB2
Net Price: $5,439.20 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | ITT / Envizion |
|---|---|
| Product Type | Valves |
| Product Subtype | Diaphragm Valves |
| Size 1 | 2" |
| Connection Type 1 | Tri-Clamp |
| Diaphragm Material | Teflon |
| Weight | 28.60000 |
- Manufacturer:
- Williams Carver Company
- MPN:
- ENV-2-F-419-SF2-0-0-TMZ-ZB2
Dimensional Data
EnviZion Diaphragm Value TC ZB Actuator
| Valve Size | C | D | E | F | G | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 0.75 | 19.05 | 4.0 | 102 | 8.03 | 204 | 8.61 | 219 | 4.56 | 116 | 3.88 | 98 |
| 1.00 | 25.4 | 4.5 | 114 | 8.03 | 204 | 8.61 | 219 | 4.56 | 116 | 3.88 | 98 |
| 1.50 | 38.1 | 5.5 | 140 | 11.84 | 301 | 12.67 | 322 | 6.41 | 163 | 5.94 | 151 |
| 2.00 | 50.8 | 6.25 | 159 | 12.14 | 309 | 13.10 | 333 | 6.41 | 163 | 5.94 | 151 |
