WILDEN XHS430S DIAPHRAGM PUMP 1.5" ANSI FLANGED HIGH PRESSURE BOLTED METAL ATEX SS WET SIDE SS PISTON ALUMINUM CHAMBER ALUMINUM CENTER ALUMINUM AIR SANITARY WIL-FLEX DIAPHRAGM WIL-FLEX VALVE BALL SS SEATS PTFE O-RINGS AODD

XHS430SSSAAAFWSWFSTF

MPN:
04-13471

USUALLY SHIPS IN 1-3 DAYS

Net Price: $7,831.00 / EA

Have an account? Login now.

This item is non-returnable.

Availability:
  • Total: 1
Product Availability
Price
WILDEN REPAIR KIT AIR 1.5" 2" ORIGINAL METAL

$700.50 / EA

  • Total: 1
Brand Wilden
Product Type Pumps
Product Subtype Diaphragm Pumps
Series High Pressure Series
Model XHS430
Material Stainless Steel
Size 1 1.5"
Connection Type 1 Flange
Diaphragm Material Wil-Flex®
Weight 64.00000
Manufacturer:
PSG California LLC
MPN:
04-13471

HS430 Dimensional DiagramHS430 Dimensional Diagram 2

HS430 Dimensional Diagram
A B C D E F G H J K L M N
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
17.4 442 3.1 80 12.7 324 20.9 531 24.0 609 23.9 606 4.9 125 4.8 122 2.0 50 5.2 132 13.1 334 20.9 531 12.3 312
