ALL-FLO S100 DIAPHRAGM PUMP 1" NPT BOLTED METAL ALUMINUM WET SIDE ALUMINUM AIR SIDE SANTOPRENE DIAPHRAGM EPDM MAX-PASS VALVE BALL ALUMINUM SEATS EPDM O-RINGS S SERIES AODD
S100-NAA-SEAE-B30
- MPN:
- S100-NAA-SEAE-B30
Net Price: $1,490.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | All-Flo |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | S Series |
| Model | S100 |
| Material | Aluminum |
| Size 1 | 1" |
| Connection Type 1 | NPT |
| Diaphragm Material | Santoprene |
| Weight | 26.00000 |
- Manufacturer:
- All-Flo
- MPN:
- S100-NAA-SEAE-B30
Dimensional Data
Air-Operated Double-Diaphragm Pump | S100 (Metal)
| Size | A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | |||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 1.00 | 25.40 | 11.60 | 294.64 | 7.50 | 190.50 | 1.30 | 33.02 | 6.90 | 175.26 | 13.00 | 330.20 | 1.50 | 38.10 | 12.40 | 314.96 | 8.40 | 213.36 | 9.10 | 231.14 | 0.40 | 10.16 | 7.30 | 185.42 | 6.30 | 160.02 | 3.30 | 83.82 | 1.30 | 33.02 | 4.00 | 101.60 | 5.20 | 132.08 |
Resources
1Manuals
All-Flo S100 Metal Manual
22D Drawings
All-Flo S100 Metal 2D Drawing
33D Models
4Performance Curves
5Spare Part Lists
8Other Literature
