Wilden
WILDEN P025 DIAPHRAGM PUMP 0.25" FPT CLAMPED PLASTIC PRO-FLO POLY WET SIDE NO PISTON POLY CENTER POLY AIR PTFE WITH NEOPRENE BACKUP IPD DIAPHRAGM PTFE VALVE BALL POLY SEATS PTFE ENCAPSULATED VITON O-RINGS AODD
P025PZPPPTNLTFPTV
- MPN:
- 00-9616
Net Price: $611.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | Wilden |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | Pro-Flo Series |
| Model | P025 |
| Material | Polypropylene |
| Size 1 | 0.25" |
| Connection Type 1 | FNPT |
| Diaphragm Material | Teflon / Neoprene |
| Weight | 3.40000 |
- Manufacturer:
- PSG California LLC
- MPN:
- 00-9616
Dimensional Data
P025 Clamped Plastic AODD Pump
| A | B | C | D | E | F | G | H | J | K | L | M | N | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 5.7 | 144.00 | 1.00 | 25.00 | 3.70 | 93.00 | 5.60 | 141.00 | 6.50 | 164.00 | 2.20 | 55.00 | 1.20 | 30.00 | 4.60 | 116.00 | 2.90 | 73.00 | 2.40 | 60.00 | 2.10 | 53.00 | 2.50 | 64.00 | 0.20 | 6.00 |
