Wilden
WILDEN P1500 DIAPHRAGM PUMP 3" ANSI FLANGED BOLTED PLASTIC PRO-FLO PVDF WET SIDE PVDF PISTON POLY CENTER POLY AIR PTFE WITH NEOPRENE BACKUP DIAPHRAGM PTFE VALVE BALL PVDF SEATS PTFE ENCAPSULATED VITON O-RINGS AODD
P1500KKPPPTNUTFKTV
- MPN:
- 15-10671
Net Price: $29,715.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
- Total: 2
| Product | Availability |
Price
|
||
|---|---|---|---|---|
| WILDEN REPAIR KIT WET 3" ADVANCED PLASTIC PTFE W/ NEOPRENE |
$3,911.80 / EA |
|
||
| WILDEN REPAIR KIT AIR 3" ADVANCED PLASTIC |
$1,430.50 / EA |
|
- Total: 2
Suggested products
Attributes
| Brand | Wilden |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | Pro-Flo Series |
| Model | P1500 |
| Material | PVDF |
| Size 1 | 3" |
| Connection Type 1 | Flange |
| Diaphragm Material | Teflon / Neoprene |
| Weight | 335.00000 |
- Manufacturer:
- PSG California LLC
- MPN:
- 15-10671
Dimensional Data
P1500 PVDF
| A | B | C | D | E | F | G | H | J | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 36.00 | 914.00 | 6.30 | 160.00 | 27.30 | 694.00 | 50.30 | 1278.00 | 7.10 | 180.00 | 11.90 | 303.00 | 46.60 | 1183.00 | 27.30 | 694.00 | 23.00 | 584.00 |
