Wilden
WILDEN P2 DIAPHRAGM PUMP 1" FPT CLAMPED METAL SS WET SIDE SS PISTON POLY CENTER POLY AIR PTFE WITH WIL-FLEX BACKUP DIAPHRAGM PTFE VALVE BALL SS SEATS PTFE O-RINGS AODD
P2SSPPPTWSTFSTF2000
- MPN:
- 02-12446
Net Price: $3,304.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
- Total: 2
| Product | Availability |
Price
|
||
|---|---|---|---|---|
| WILDEN REPAIR KIT AIR 1" COMBO PLASTIC |
$440.00 / EA |
|
||
| WILDEN REPAIR KIT WET 1" ORIGINAL METAL PTFE |
$719.70 / EA |
|
- Total: 2
Suggested products
Attributes
| Brand | Wilden |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | Pro-Flo Series |
| Model | P2 |
| Material | Stainless Steel |
| Size 1 | 1" |
| Connection Type 1 | FNPT |
| Size 2 | 1" |
| Diaphragm Material | Teflon |
| Weight | 37.00000 |
- Manufacturer:
- PSG California LLC
- MPN:
- 02-12446
Dimensional Data
P2 Clamped Metal Dimensional Diagram
| A | B | C | D | E | F | G | H | J | K | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 10.80 | 274.00 | 1.50 | 38.00 | 6.40 | 163.00 | 10.00 | 254.00 | 10.80 | 274.00 | 1.10 | 28.00 | 3.20 | 81.00 | 4.90 | 124.00 | 6.40 | 163.00 | 11.90 | 302.00 |
Resources
0Data Sheets
Wilden Pro-Flo P2 Clamped Metal Data Sheet
1Manuals
22D Drawings
Wilden Pro-Flo P2 Clamped Metal 2D Drawing
33D Models
