Wilden
WILDEN P800 DIAPHRAGM PUMP 2" ANSI FLANGED BOLTED PLASTIC PRO-FLO PVDF WET SIDE PVDF PISTON POLY CENTER POLY AIR PTFE WITH NEOPRENE BACKUP DIAPHRAGM PTFE VALVE BALL PVDF SEATS PTFE ENCAPSULATED VITON O-RINGS CENTER PORTED ANSI/DIN COMBO AODD
P800KKPPPTNUTFKTV0690
- MPN:
- 08-13308
Net Price: $14,768.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
- Total: 2
| Product | Availability |
Price
|
||
|---|---|---|---|---|
| WILDEN REPAIR KIT AIR 1.5" 2" ADVANCED PLASTIC |
$581.60 / EA |
|
||
| WILDEN REPAIR KIT WET 2" ADVANCED PLASTIC PTFE W/ NEOPRENE |
$1,572.90 / EA |
|
- Total: 2
Suggested products
Attributes
| Brand | Wilden |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | Pro-Flo Series |
| Model | P800 |
| Material | PVDF |
| Size 1 | 2" |
| Connection Type 1 | Flange |
| Diaphragm Material | Teflon / Neoprene |
| Weight | 115.00000 |
- Manufacturer:
- PSG California LLC
- MPN:
- 08-13308
Dimensional Data
P800 Bolted Plastic Center Ported PVDF
| A | B | C | D | E | F | G | H | J | K | L | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 22.9 | 582 | 3.0 | 77 | 15.5 | 394 | 26.9 | 683 | 29.9 | 759 | 3.5 | 89 | 3.6 | 91 | 6.9 | 175 | 13.3 | 358 | 20.0 | 508 | 15.6 | 396 |
