Wilden
WILDEN XPS1520 DIAPHRAGM PUMP 3" FPT BOLTED METAL ATEX PRO-FLO SHIFT ALUMINUM WET SIDE ALUMINUM PISTON ALUMINUM CHAMBER ALUMINUM CENTER ALUMINUM AIR NEOPRENE DIAPHRAGM NEOPRENE VALVE BALL NEOPRENE SEATS AODD
XPS1520AAAAANESNENE
- MPN:
- 15-12386
Net Price: $4,384.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
- Total: 2
| Product | Availability |
Price
|
||
|---|---|---|---|---|
| WILDEN REPAIR KIT AIR 3" 4" ORIGINAL METAL |
$977.60 / EA |
|
||
| WILDEN REPAIR KIT WET 3" ADVANCED ALUMINUM NEOPRENE |
$639.10 / EA |
|
- Total: 2
Suggested products
Attributes
| Brand | Wilden |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | Pro-Flo Shift Series |
| Model | XPS1520 |
| Material | Aluminum |
| Size 1 | 3" |
| Connection Type 1 | FNPT |
| Diaphragm Material | Neoprene |
| Weight | 152.00000 |
- Manufacturer:
- PSG California LLC
- MPN:
- 15-12386
Dimensional Data
XPS1520 Aluminum
| A | B | C | D | E | F | G | H | J | K | L | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 25.0 | 635 | 2.4 | 61 | 16.8 | 426 | 29.9 | 759 | 32.2 | 818 | 3.3 | 84 | 16.3 | 414 | 1.9 | 48 | 8.3 | 211 | 7.4 | 189 | 28.4 | 720 |
Resources
0Data Sheets
Wilden Pro-Flo Shift PS1520 PS1530 Bolted Metal Data Sheet
1Manuals
22D Drawings
Wilden Pro-Flo Shift PS1520 Bolted Metal 2D Drawing
33D Models
