Wilden
WILDEN XPS4 DIAPHRAGM PUMP 1.5" 2" TC CLAMPED METAL ATEX PRO-FLO SHIFT IRON WET SIDE STEEL PISTON ALUMINUM CHAMBER ALUMINUM CENTER ALUMINUM AIR NEOPRENE DIAPHRAGM NEOPRENE VALVE BALL NEOPRENE SEATS AODD
XPS4WMAAANESNENE
- MPN:
- 04-12976
Net Price: $2,225.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
- Total: 2
| Product | Availability |
Price
|
||
|---|---|---|---|---|
| WILDEN REPAIR KIT AIR 1.5" 2" ORIGINAL METAL |
$700.50 / EA |
|
||
| WILDEN REPAIR KIT WET 1.5" COMBO METAL NEOPRENE |
$272.20 / EA |
|
- Total: 2
Suggested products
Attributes
| Brand | Wilden |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | Pro-Flo Shift Series |
| Model | XPS4 |
| Material | Cast Iron |
| Size 1 | 2" |
| Connection Type 1 | Tri-Clamp |
| Diaphragm Material | Neoprene |
| Weight | 66.00000 |
- Manufacturer:
- PSG California LLC
- MPN:
- 04-12976
Dimensional Data
PS4 Metal Dimensional Diagram
| A | B | C | D | E | F | G | H | J | K | L | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 14.5 | 368 | 2.5 | 64 | 8.9 | 225 | 16.9 | 429 | 8.4 | 213 | 1.9 | 48 | 5.4 | 138 | 13.4 | 340 | 13.2 | 334 | 21.1 | 537 | 21.0 | 532 |
