Alfa Laval 700 Series Throttling Valve 2.5" Tri-Clamp 316L Buna Normally Closed

771S-10M-20-2.5-316L

MPN:
9634099734

Net Price: $4,424.44 / EA

Have an account? Login now.

This item is non-returnable.

Availability:
  • Total: 1
Product Availability
Price
SERVICE KIT 2.5" BUNA 761 741 771 10-30 SERIES

$30.09 / EA

  • Total: 1
Brand Alfa Laval
Product Type Valves
Product Subtype Seat Valves
Series 700 Series
Model 771
Material 316L Stainless Steel
Elastomer Buna
Size 1 2.5"
Connection Type 1 Tri-Clamp
Weight 23.02000
Manufacturer:
Alfa Laval Inc
MPN:
9634099734

771-10 Throttling Shutoff TC Dimensional Diagram

771-10 Shutoff Throttling Tri-Clamp Single Seat Valve
Nominal Size A C
(in) (mm) (in) (mm) (in) (mm)
1 25.40 14.13 358.90 2.50 63.50
1½ 38.10 15.06 382.52 2.75 69.85
2 50.80 15.56 395.22 3.50 88.90
2½ 63.50 15.50 393.70 3.50 88.90
3 76.20 15.50 393.70 3.75 95.25
