Alfa Laval
Alfa Laval Throttling Shutoff Valve 2.5" Butt Weld 316L EPDM Seal N/C Actuator Moore KV106
7710-200SW2H252SSSDES
- MPN:
- 9613363167
Net Price: $4,917.52 / EA
This item is non-returnable.
- Availability:
Spare Parts
- Total: 1
| Product | Availability |
Price
|
||
|---|---|---|---|---|
| SERVICE KIT 2.5" EPDM UNIQUE SSV SHUTOFF VALVE |
$114.51 / EA |
|
- Total: 1
Suggested products
Attributes
| Brand | Alfa Laval |
|---|---|
| Product Type | Valves |
| Product Subtype | Seat Valves |
| Series | Unique RV-ST Series |
| Material | 316L Stainless Steel |
| Finish | 32Ra ID |
| Elastomer | EPDM |
| Size 1 | 2.5" |
| Connection Type 1 | Butt Weld |
| Weight | 0.00000 |
- Manufacturer:
- Alfa Laval Inc
- MPN:
- 9613363167
Dimensional Data
Unique SSV Regulating Tri-Clamp Single Seat Valve
| Nominal Size | A | E | H | ||||
|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 1½ | 38.10 | 21.40 | 543.56 | 1.95 | 49.53 | 3.35 | 85.09 |
| 2 | 50.80 | 23.37 | 593.60 | 2.44 | 61.98 | 4.52 | 114.81 |
| 2½ | 63.50 | 24.40 | 619.76 | 3.23 | 82.04 | 4.52 | 114.81 |
| 3 | 76.20 | 25.71 | 653.03 | 3.43 | 87.12 | 6.07 | 154.18 |
| 4 | 101.60 | 27.50 | 698.50 | 4.72 | 119.89 | 6.07 | 154.18 |
Resources
0Data Sheets
Alfa Laval Unique SSV Standard Data Sheet
