Alfa Laval
PLUG VALVE 1.5" TC 3-WAY TRI CLOVER
D11MP-1.5-S
- MPN:
- 201359
Net Price: $2,621.95 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | Alfa Laval |
|---|---|
| Product Type | Valves |
| Product Subtype | Plug Valves |
| Series | D10 / D11 Series |
| Size 1 | 1.5" |
| Connection Type 1 | Tri-Clamp |
| Weight | 9.80000 |
- Manufacturer:
- Alfa Laval Inc
- MPN:
- 201359
Dimensional Data
D11 Tri CLamp 3-Way Valve
| Nominal Size | A | B | C | D | E | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 1½ | 38.1 | 2.91 | 73.8 | 5.83 | 147.6 | 7.00 | 177.8 | 5.63 | 142.9 | 2.50 | 63.5 |
| 2 | 50.8 | 3.41 | 86.5 | 6.83 | 173.0 | 7.63 | 193.7 | 5.63 | 142.9 | 2.88 | 73.0 |
| 2½ | 63.5 | 4.13 | 104.8 | 8.25 | 209.6 | 8.75 | 222.3 | 6.25 | 158.8 | 3.50 | 88.9 |
| 3 | 76.2 | 4.72 | 119.9 | 9.44 | 239.7 | 9.75 | 247.7 | 7.25 | 184.2 | 3.75 | 95.3 |
Resources
0Data Sheets
Alfa Laval D10 D11 Data Sheet
