Wilden
WILDEN A1 DIAPHRAGM PUMP 0.5" FPT CLAMPED METAL PRO-FLO BASE SS WET SIDE SS PISTON POLY CENTER POLY AIR SANIFLEX DIAPHRAGM SANIFLEX VALVE BALL SS SEATS SANIFLEX O-RINGS 24V AC 12V DC COIL AODD
A1PSSPPPFSSFSSFS0128
- MPN:
- 01-10435
Net Price: $3,637.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | Wilden |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | Accu-Flo Series |
| Model | A1 |
| Material | Stainless Steel |
| Size 1 | 0.5" |
| Connection Type 1 | FNPT |
| Diaphragm Material | Saniflex |
| Weight | 22.60000 |
- Manufacturer:
- PSG California LLC
- MPN:
- 01-10435
Dimensional Data
A1P Plastic
| A | B | C | D | E | F | G | H | J | K | L | M | N | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 1.16 | 30.00 | 4.59 | 117.00 | 7.69 | 196.00 | 9.56 | 244.00 | 8.19 | 208.00 | 8.63 | 218.00 | 2.00 | 51.00 | 3.50 | 89.00 | 7.50 | 191.00 | 4.56 | 117.00 | 5.56 | 142.00 | 2.16 | 56.00 | 9.06 | 231.00 |
