WILDEN A2 DIAPHRAGM PUMP 1" FPT CLAMPED METAL ADAPTER BLOCK BASE ALUMINUM WET SIDE ALUMINUM PISTON POLY CENTER POLY AIR BUNA DIAPHRAGM BUNA VALVE BALL ALUMINUM SEATS BUNA O-RINGS ADAPTER BLOCK NO MUFFLER PRO-FLO CENTER SECTION AODD

A2BAAPPPBNSBNABN2512

MPN:
02-12542

USUALLY SHIPS IN 1-3 DAYS

Net Price: $1,254.00 / EA

Have an account? Login now.

This item is non-returnable.

Availability:
  • Total: 1
Product Availability
Price
WILDEN REPAIR KIT WET 1" ORIGINAL METAL BUNA

$231.10 / EA

  • Total: 1
Brand Wilden
Product Type Pumps
Product Subtype Diaphragm Pumps
Series Accu-Flo Series
Model A2
Material Aluminum
Size 1 1"
Connection Type 1 FNPT
Size 2 1"
Diaphragm Material Buna
Weight 20.00000
Manufacturer:
PSG California LLC
MPN:
02-12542

A2B Clamped Metal Dimensional DiagramA2B Clamped Metal Dimensional Diagram.2

A2B Clamped Metal
A B C D E F G H J
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
10.5 267.0 1.4 36.0 5.7 145.0 6.6 168.0 10.0 254.0 11.0 279.0 1.1 28.0 2.6 66.0 6.8 173.0
