Alfa Laval
DIAPHRAGM VALVE DV-ST ULTRAPURE 0.75" TC EPDM 316L CAST SS/SS BPE SF4 EP MANUAL HANDLE WITH Q-DOC ALFA LAVAL
DVSTSOOT20XXA4MASSEEN1NNN
Net Price: $787.27 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | Alfa Laval |
|---|---|
| Product Type | Valves |
| Product Subtype | Diaphragm Valves |
| Series | DV-ST UltraPure Series |
| Material | 316L Stainless Steel |
| Size 1 | 0.75" |
| Connection Type 1 | Tri-Clamp |
| Diaphragm Material | EPDM |
| Weight | 1.50000 |
Dimensional Data
DVST 2 Way TC Cast Manual Handle Diaphragm Valve
| Nominal Size | D | H | L | ||||
|---|---|---|---|---|---|---|---|
| (in) | (DN) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| ¼-⅜ | 8-10 | 1.57 | 40.00 | 2.87 | 73.00 | 3.50 | 89.00 |
| ½ | 15 | 1.57 | 40.00 | 2.87 | 73.00 | 4.25 | 108.00 |
| ¾ | 20 | 2.44 | 62.00 | 4.09 | 104.00 | 4.65 | 118.00 |
| 1 | 25 | 2.44 | 62.00 | 4.53 | 115.00 | 5.00 | 127.00 |
| 1½ | 40 | 3.42 | 87.00 | 5.20 | 132.00 | 6.26 | 159.00 |
| 2 | 50 | 4.25 | 108.00 | 6.14 | 156.00 | 7.52 | 191.00 |
| 2½ | 65 | 4.25 | 108.00 | 7.99 | 203.00 | 8.50 | 216.00 |
| 3 | 80 | 6.78 | 172.00 | 9.09 | 231.00 | 10.00 | 254.00 |
| 4 | 100 | 8.66 | 220.00 | 10.55 | 268.00 | 11.96 | 305.00 |
