ALL-FLO A150 DIAPHRAGM PUMP 1.5" ANSI DIN FLANGE BOLTED METAL 316 STAINLESS STEEL WET SIDE ALUMINUM AIR SIDE GEOLAST DIAPHRAGM GEOLAST VALVE BALL 316 STAINLESS STEEL SEATS BUNA-N O-RINGS AODD

A150-FA3-GG3N-G70

USUALLY SHIPS IN 1-3 DAYS

Net Price: $4,684.00 / EA

Have an account? Login now.

Availability:
  • Total: 2
Product Availability
Price
ALL-FLO REPAIR KIT AIR 1.5" BOLTED ALUMINUM

$394.00 / EA

ALL-FLO REPAIR KIT WET 1.5" BOLTED METAL GEOLAST

$556.00 / EA

  • Total: 2
Brand All-Flo
Product Type Pumps
Product Subtype Diaphragm Pumps
Series A Series
Model A150
Material 316 Stainless Steel
Size 1 1.5"
Connection Type 1 Flange
Diaphragm Material Geolast
Weight 96.00000

A150 Dimensional Diagram (Flange, Dimensions A, B, C, and D)A150 Dimensional Diagram (Flange, Dimensions E, F, G, and H)A150 Dimensional Diagram (Flange, Dimensions I, J, K, L, M, N, O, and P)

Air-Operated Double-Diaphragm Pump (Flanged) | A150
Size A B C D E F G H I J K L M N O P
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
1.50 38.10 20.90 530.86 12.60 320.04 3.10 78.74 18.80 477.52 3.20 81.28 23.90 607.06 10.70 271.78 11.20 284.48 0.60 15.24 7.00 177.80 6.00 152.40 4.00 101.60 1.80 45.72 5.80 147.32 8.80 223.52 10.60 269.24
