ALL-FLO A150 DIAPHRAGM PUMP 1.5" NPT BOLTED METAL 316 STAINLESS STEEL WET SIDE 316 STAINLESS STEEL AIR SIDE PTFE DIAPHRAGM PTFE VALVE BALL 316 STAINLESS STEEL SEATS PTFE O-RINGS METAL MUFFLER AODD

A150-N33-TT3T-B80

USUALLY SHIPS IN 1-3 DAYS

Net Price: $7,151.00 / EA

Have an account? Login now.

This item is non-returnable.

Availability:
  • Total: 2
Product Availability
Price
All-Flo Repair Kit Wet End PTFE for 1.5" Bolted Metal Pumps

$1,221.30 / EA

ALL-FLO REPAIR KIT AIR 1.5" BOLTED STAINLESS STEEL

$564.70 / EA

  • Total: 2
Brand All-Flo
Product Type Pumps
Product Subtype Diaphragm Pumps
Series A Series
Model A150
Material 316 Stainless Steel
Size 1 1.5"
Connection Type 1 NPT
Diaphragm Material PTFE (Teflon)
Weight 99.00000

A150 Dimensional Diagram (Bolted, Dimensions A, B, C, D, E, and F)A150 Dimensional Diagram (Bolted, Dimensions G, H, I, and J)A150 Dimensional Diagram (Bolted, Dimensions K, L, M, N, O, P, Q, and R)

Air-Operated Double-Diaphragm Pump (Bolted) | A150
Size A B C D E F G H I J K L M N O P Q R
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
1.50 38.10 15.40 391.16 10.40 264.16 2.50 63.50 0.50 12.70 11.40 289.56 20.80 528.32 1.60 40.64 17.30 439.42 10.70 271.78 11.20 284.48 0.60 15.24 7.00 177.80 5.30 (Aluminum) 134.62 4.00 101.60 1.80 45.72 5.80 147.32 8.80 223.52 11.10 281.94
1.50 38.10 15.40 391.16 10.40 264.16 2.50 63.50 0.50 12.70 11.40 289.56 20.80 528.32 1.60 40.64 17.30 439.42 10.70 271.78 11.20 284.48 0.60 15.24 7.00 177.80 6.00 (Steel) 152.40 4.00 101.60 1.80 45.72 5.80 147.32 8.80 223.52 11.10 281.94
