ALL-FLO C038 DIAPHRAGM PUMP 0.375" NPT(BSP) CLAMPED PLASTIC POLYPROPYLENE WET SIDE POLYPROPYLENE AIR SIDE GEOLAST DIAPHRAGM PTFE VALVE BALL POLYPROPYLENE SEATS BUNA-N O-RINGS AODD

C038-SQP-GTPN-S70

USUALLY SHIPS IN 1-3 DAYS

Net Price: $582.00 / EA

Have an account? Login now.

This item is non-returnable.

Availability:
Brand All-Flo
Product Type Pumps
Product Subtype Diaphragm Pumps
Series C Series
Model C038
Material Polypropylene
Size 1 0.375"
Connection Type 1 NPT
Diaphragm Material Geolast
Weight 5.00000

C038 Dimensional Diagram (Dimensions A, B, C, D, and E)C038 Dimensional Diagram (Dimensions F, G, H, I, and J)

Air-Operated Double-Diaphragm Pump | C038
Size A B C D E F G H I J
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm) (in) (mm)
0.38 9.53 8.55 217.17 6.63 168.40 4.06 103.12 4.21 106.93 0.15 3.81 4.82 122.43 7.19 182.63 3.86 98.04 1.06 26.92 2.40 60.96
