90 DEGREE REDUCING ELBOW 2X1.5 TC 304 32RA ID 32RA OD
2CMP-31MP-2X1.5-304-7
Net Price: $197.37 / EA
- Availability:
Spare Parts
Suggested products
Attributes
| Product Type | Tube Fittings |
|---|---|
| Product Subtype | Elbows |
| Material | 304 Stainless Steel |
| Finish | 32Ra ID / 32Ra OD |
| Size 1 | 2" |
| Connection Type 1 | Tri-Clamp |
| Size 2 | 1.5" |
| Connection Type 2 | Tri-Clamp |
| Shape | 90 Degree |
| Specification / Standard | 3-A |
| Fitting Design | 2CMP-31MP |
| Weight | 0.75000 |
Dimensional Data
Reducing Tri-Clamp Tees | 2CMP-31MP-Size-Material-Finish
| Nominal Size | A | B | |||
|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 2 x 1 | 50.80 x 25.40 | 2.00 | 50.80 | 2.00 | 50.80 |
| 2 x 1½ | 50.80 x 38.10 | 2.75 | 69.85 | 2.75 | 69.85 |
| 2½ x 2 | 63.50 x 50.80 | 3.50 | 88.90 | 3.50 | 88.90 |
| 3 x 2 | 76.20 x 50.80 | 3.50 | 88.90 | 3.50 | 88.90 |
| 3 x 2½ | 76.20 x 63.50 | 4.25 | 107.95 | 4.25 | 107.95 |
| 4 x 3 | 101.60 x 76.20 | 5.00 | 127.00 | 5.13 | 130.30 |
