Wilden
WILDEN XPS1520 DIAPHRAGM PUMP 3" FPT CLAMPED METAL ATEX PRO-FLO SHIFT SS WET SIDE SS PISTON SS CHAMBER SS CENTER SS AIR SANITARY WIL-FLEX DIAPHRAGM WIL-FLEX VALVE BALL WIL-FLEX SEATS AODD
XPS1520SSSSSFWSFWSTF
Net Price: $18,830.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
Suggested products
Attributes
| Brand | Wilden |
|---|---|
| Product Type | Pumps |
| Product Subtype | Diaphragm Pumps |
| Series | Pro-Flo Shift Series |
| Model | XPS1520 |
| Material | Stainless Steel |
| Size 1 | 2" |
| Connection Type 1 | FNPT |
| Diaphragm Material | Wil-Flex® |
| Weight | 390.00000 |
Dimensional Data
XPS1520 Stainless Steal
| A | B | C | D | E | F | G | H | J | K | L | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 25.6 | 650 | 2.8 | 71 | 17.5 | 443 | 30.1 | 765 | 32.1 | 815 | 2.8 | 71 | 17.0 | 431 | 1.9 | 48 | 8.3 | 211 | 7.3 | 184 | 28.2 | 715 |
