Ampco
Ampco ZCH2 Centrifugal Pump and Motor 6" x 6" Flange 316L CER/C Single Mechanical Buna 10" Impeller 284JM 30HP 1750 RPM TEFC Baldor
ZCH2S1580F28JMS5UN-30LTB
Net Price: $20,675.00 / EA
This item is non-returnable.
- Availability:
Spare Parts
- Total: 1
| Product | Availability |
Price
|
||
|---|---|---|---|---|
| SEAL KIT C/CER BUNA ZCH2 6X6 1.6250" TYPE 21 AMPCO |
$595.00 / EA |
|
- Total: 1
Suggested products
Attributes
| Brand | Ampco |
|---|---|
| Motor Brand | Baldor |
| Product Type | Pumps |
| Product Subtype | Centrifugal Pumps |
| Series | Z Series |
| Model | ZCH2 |
| Material | 316 Stainless Steel |
| Elastomer | Buna |
| Size 1 | 6" |
| Connection Type 1 | Flange |
| Size 2 | 6" |
| Connection Type 2 | Flange |
| Enclosure | TEFC |
| Horsepower | 30HP |
| Motor Speed | 1750 RPM |
| Seal Type | Single Mechanical |
| Seal Material | Ceramic / Carbon |
| Weight | 774.00000 |
Dimensional Data
ZCH2 6 x 6
| TEFC Motor | A | B | D | E | F | L | CP | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HP | RPM | Frame | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) |
| 10 | 1750 | 215JP | 9.50 | 241.30 | 8.00 | 203.20 | 5.25 | 133.35 | 4.25 | 107.95 | 7.00 | 177.80 | 17.00 | 431.80 | 28.06 | 712.72 |
| 15 | 1750 | 254JP | 11.50 | 292.10 | 9.75 | 247.65 | 6.25 | 158.78 | 5.00 | 127.00 | 8.25 | 209.55 | 17.25 | 438.15 | 30.31 | 769.87 |
| 20 | 1750 | 256JP | 11.50 | 292.10 | 11.50 | 292.10 | 6.25 | 158.78 | 5.00 | 127.00 | 10.00 | 254.00 | 17.25 | 438.15 | 32.19 | 817.63 |
| 25 | 1750 | 284JP | 12.75 | 323.85 | 12.75 | 323.85 | 7.00 | 177.80 | 5.50 | 139.70 | 9.50 | 241.30 | 17.25 | 438.15 | 35.69 | 906.53 |
| 30 | 1750 | 286JP | 12.75 | 323.85 | 12.75 | 323.85 | 7.00 | 177.80 | 5.50 | 139.70 | 11.00 | 279.40 | 17.25 | 438.15 | 36.31 | 922.27 |
