ADAPTER 1" TC X HOSE BARB 316L 3.5" OAL

14MPHRXL-1-316L-7

USUALLY SHIPS IN 1-2 DAYS

LEAD TIMES MAY VARY BECAUSE THIS IS AN ASSEMBLED OR MANUFACTURED PART

Net Price: $135.08 / EA

Have an account? Login now.

Availability:
Product Type Tube Fittings
Product Subtype Adapters
Material 316L Stainless Steel
Finish 32Ra ID / 32Ra OD
Size 1 1"
Connection Type 1 Tri-Clamp
Size 2 1"
Connection Type 2 Hose Barb
Length 3.5" OAL
Fitting Design 14MPHRXL
Weight 0.31250

14MPHRXL Dimensional Diagram

Tri-Clamp x Hose Barb Brewery Style (XL) Adapter | 14MPHRXL-Size-Material-Finish
Nominal Size A B # of Barbs
(in) (mm) (in) (mm) (in) (mm)
⅜ 9.53  2.25 57.15 0.375 9.750 5
½ 12.70  2.25 57.15 0.500 12.70 5
¾ 19.05 2.25 57.15 0.750 19.00 5
1 25.40 3.50 88.90 1.000 25.40 10
1½ 38.10 3.50 88.90 1.500 38.10 10
2 50.80 3.50 88.90 2.000 50.80 10
2½ 63.50 3.50 88.90 2.500 63.50 10
3 76.20 3.50 88.90 3.000 76.20 10
